Cloudray UV-5 5W UV Laser Marking Engraver Enclosure

The Cloudray UV-5 UV Laser Marker Enclosure by Clearview Plastics is a made-to-fit safety and ventilation enclosure for the Cloudray UV-5 — the 5W, 355 nm UV marker. Its fully transparent OD3+ laser-filtering acrylic panels give you a clear view from every side while blocking 99.9%+ of stray 355 nm UV light and containing the fumes and ozone.

Offered in multiple sizes so you can match the UV-5 or size up to your media, it's a "set-over" enclosure that assembles in 20–30 minutes and can ship flat-packed or delivered assembled.

Not sure on size, or want a higher-rated OD6+ window? See our universal UV OD3+ enclosure or the heavy-duty UV / Fiber Galvo enclosure.

Full visibility with real UV light-filtering

UV "cold" lasers mark without burning, but 355 nm is still a Class 4 hazard to eyes and skin, and the photochemical process gives off ozone and fine fume. This enclosure keeps the view open while cutting the danger:

• OD3+ laser-filtering acrylic — spectrometer-tested to block 99.9%+ (1000×+ reduction) of 355 nm laser light, so stray beams are dramatically attenuated.
• Fully transparent panels on all sides — front, back, sides, and top, for the best possible workpiece visibility.
• Door gasketing — seals the door perimeter to keep fumes and ozone in and block light leakage around the edges.

Note: the OD3+ panels dramatically reduce stray-light exposure and are spectrometer tested. However they do not reclassify your Class 4 laser. Always wear OD-rated UV safety glasses while the laser is in use.

Contain the fumes and ozone

• 4" exhaust adapter — connects a flexible 4" hose on the rear panel to vent outdoors or to a filter.
• Fan & venting options — add a 95 CFM or 200 CFM fan, or our window exhaust kit, for the extraction your workload needs.
• Donaldson AD350 filter — step up to a heavier-duty Donaldson AD350 filtration unit purpose-built for laser marking when venting outside isn't an option.
• Flow-control vents — slide-open vents on the front and sides tune airflow for better extraction.

Configure your enclosure

• Size — choose the size that matches your machine and media.
• HD hardware upgrade — metal hinges, heavier binding-screw hardware, and metal door pulls.
• LightBurn hood camera — hood-mounted USB camera for accurate part alignment and LightBurn tracing.
• Additional side doors — with two side doors the enclosure doubles as a pass-through for oversized or long media.
• Additional seam sealing — extra sealing for tighter fume, ozone, and light containment.
• Magnetic door interlock switch — a 2-wire interlock lead to tie into your machine's safety circuit.
• Delivered assembled — have it shipped built and ready to use instead of flat-packed.

Specifications

• Fits: Cloudray UV-5 (355 nm UV galvo), plus other desktop UV markers — see sizing options
• Panels: 1/4" fully transparent OD3+ laser-filtering acrylic (front, back, sides, top)
• Protection: OD3+ at 355 nm — blocks 99.9%+ (1000×+ reduction) of stray UV light, spectrometer-tested
• Sizes: multiple sizes — choose yours in the configurator above
• Exhaust: 4" adapter (rear); fan, window-kit, or Donaldson AD350 filtration options; slide flow-control vents
• Sealing: door gasketing standard; optional added seam sealing
• Options: HD hardware, LightBurn hood camera, additional side doors (pass-through), magnetic door interlock (2-wire), assembled delivery
• Made in: Sacramento, California, USA

Why choose the Clearview UV OD3+ enclosure

• See everything — fully transparent OD3+ acrylic on all sides for the clearest workpiece view.
• Real UV filtering — spectrometer-tested OD3+ blocks 99.9%+ of 355 nm stray light.
• Contains fumes and ozone — with exhaust and Donaldson AD350 filtration options.
• Configurable for real shops — sizes, side doors / pass-through, interlock, seam sealing, and assembled delivery.
• US-made by a small business — CNC-cut in Sacramento with genuine, hands-on support.

About Clearview Plastics

Neil Henderson here, owner and head designer at Clearview Plastics. My shop is a California-based artisan design studio, and we build every enclosure in-house in Sacramento. Our panels are professionally CNC-cut for accuracy, with parts designed specifically for each machine we support — this isn't a generic box off a marketplace. When you order through us, you work directly with me, and that relationship comes with my genuine appreciation and skilled, personal help.

Frequently asked questions

What does an OD3+ rating mean?
OD3+ means less than 0.1% (one-thousandth) of a beam's power can get through the panel — a 1,000×+ reduction — spectrometer-tested above OD3 across the relevant wavelengths. It's safe for incidental viewing during normal operation, but it is not a certified laser-viewing window and does not reclassify your laser.

Should I get this or the OD6+ heavy-duty enclosure?
This OD3+ acrylic enclosure gives the clearest all-around visibility. For a higher-rated OD6+ UV window with aluminum-composite panels and a more industrial build, choose our UV / Fiber Galvo Laser Marker Enclosure.

What are the exhaust and filtration options?
A 4" exhaust adapter is included. Add a 95 CFM or 200 CFM fan or our window exhaust kit, or step up to a heavy-duty Donaldson AD350 laser-rated filtration unit for indoor operation.

Can it act as a pass-through for long media?
Yes — add the optional side doors; with two side doors the enclosure opens on both sides to pass long or large stock straight through.

Can I get it assembled?
Yes. Choose the delivered-assembled option; you can also add a magnetic door interlock (2-wire lead) and extra seam sealing.

What is your return policy?
30-day return policy. Unused, undamaged panels with masking fully attached are eligible for a full refund less return shipping. Damaged or unmasked panels are not refundable.
